Vision sensors for automation technology VeriSens

BAUMER
sensor technology

Object detection

Image identification 2D/3D

The company Baumer is an international business with a passion for sensor technology, encoders, measuring instruments and components for automated image processing. Through a very strong local presence in 39 subsidiaries and 19 countries, Baumer is able to be close to the customers. The outstanding Baumer quality of the vast portfolio of sensors and instruments keeps the company on the road of success in tough international competition. Various expert juries awarded Baumer with national and international prizes for innovation, design and quality as a token for quality and pioneering spirit.

VeriSens is a complete image processing system in the shape of a sensor. Typical applications among many others are packaging and quality inspection. As an inline solution, different product features can be easily verified directly after a manufacturing step so that defective parts can be sorted out immediately.

Flexibility and versatility of image-based part verification is a must for many users today. VeriSens is the ideal component. As a complete image processing system, it includes all necessary hardware and software in a industry-suited housing. It can be configured intuitively using a PC.

VeriSens is a complete image processing system in the shape of a sensor. An image sensor, illumination (or illumination connection), optics (also interchangeable lenses), hardware / software, as well as Ethernet and digital interfaces, e.g. for PLC connection, are integrated in a compact, industry-suited housing. After typical one-time configuration on PC, a vision sensor is ready to perform a specific task like a conventional sensor. VeriSens vision sensors solve inspection tasks and can perform up to 32 feature checks simultaneously:

Presence and completeness checks
Determination or inspection of object position and orientation
Reading and verifying human-readable imprints (OCR / OCV)
Reading and checking matrix codes and barcodes including GS1 codes

VeriSens vision sensors: Image-based quality control – easy and intuitive
